ROGER B70/2DC/BOX Control unit

Control Board Roger B70/2DC/BOX – The Ultimate Solution for Swing Gate Automation

The Roger B70/2DC/BOX control board is the ideal solution for automating swing gates with one or two Brushless 24V motors. Designed for optimal performance and durability, this controller ensures efficient and safe operation for both residential and commercial installations.

Technical Specifications:

• Power supply: 230V AC ± 10% 50 Hz.
• Maximum absorbed power: 350W.
• Number of controlled motors: 1 or 2 Brushless 24V motors.
• Maximum power per motor: 110W.
• Protection rating: IP54, suitable for various environmental conditions.
• Operating temperature: -20°C to +55°C.
• Dimensions: 330 mm (length) x 230 mm (width) x 115 mm (height).
• Packaged weight: 3.9 kg.

Compatible Motors:
The B70/2DC/BOX is compatible with the Roger Technology Brushless motor range, including the MONOS4 Brushless 24V DC model. These motors are known for their energy efficiency and long lifespan, ensuring smooth and precise gate movement.

Additional Benefits:

• Sensorless control: No additional sensors needed, simplifying installation and reducing maintenance.
• Flexible programming: Adjust speed, slow-down, and opening/closing times according to installation needs.
• Compatibility with safety accessories: Easy integration with photocells and other safety devices for compliant operation.

Get the best price for the Roger B70/2DC/BOX in our online store today. We offer exclusive deals and expert advice to ensure top performance.
